1-14 Chapter 1: Product introduction
Side(s): SS - Single-sided DS - Double-sided
DIMM support:
A - Supports one module inserted in any slot as Single-channel
memory conguration.
B - Supports one pair of modules inserted into either the yellow slots
as one pair of Dual-channel memory conguration.
C - Supports four modules inserted into both the yellow slots as two
pairs of Dual-channel memory conguration.
Visit the ASUS website (www.asus.com) for the latest QVL.
256MB Kingston KVR533D2N4/256 Elpida SS E5116AB-5C-E • • •
256MB Kingston KVR533D2N4/256 Elpida SS E5116AF-5C-E • • •
512MB Kingston KVR533D2N4/512 Hynix DS HY5PS56821F-C4 • • •
512MB Kingston KVR533D2N4/512 Inneon SS HYB18T512800AF3733336550 • • •
1G Kingston KVR533D2N4/1G Kingston DS D6408TE7BL-37 • • •
1G Kingston KVR533D2N4/1G Micron DS 5YD11D9GCT • • •
256MB Samsung M378T3253FG0-CD5 Samsung SS K4T56083QF-GCD5 • • •
512MB Samsung M378T6553BG0-CD5 Samsung SS K4T51083QB-GCD5 • • •
256MB Qimonda HYS64T32000HU-3.7-A Qimonda SS HYB18T512160AF-3.7AFSS31270 • • •
512MB Qimonda HYS64T64000GU-3.7-A Qimonda SS HYB18T512800AC37SSS11511 • • •
512MB Qimonda HYS64T64000HU-3.7-A Qimonda SS HYB18T512800AF37SSS12079 • • •
512MB Qimonda HYS64T64000HU-3.7-A Qimonda SS HYB18T512800AF37FSS29334 • • •
512MB Micron MT 16HTF6464AG-53EB2 Micron DS D9BOM • • •
512MB Micron MT 16HTF6464AG-53EB2 Micron DS Z9BQT • • •
1G Micron MT 16HTF12864AY-53EA1 Micron DS D9CRZ • • •
512MB Corsair VS512MB533D2 Corsair DS MIII0052532M8CEC • • •
512MB Elpida EBE51UD8ABFA-5C-E Elpida SS E5108AB-5C-E • • •
512MB Transcend 512MB DDR2 533 ECC Micron SS 6ND22D9GCT(ECC) • • •
512MB Kingmax KLBC28F-A8KB4 Kingmax SS KKEA88B4IAK-37 • • •
256MB Kingmax KLBB68F-36EP4 Elpida SS E5116AB-5C-E • • •
512MB Kingmax KLBC28F-A8EB4 Elpida SS E5108AE-5C-E • • •
Size Vendor Model Brand Side(s) Component A B C
DIMM support
DDR2 533

Asus M2N-X Specifications

General

ECC	Yes
Number of memory slots	2
Maximum internal memory	4 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
CPU fan connector	No
Number of SATA connectors	4
Number of EATX power connectors	1
Manageability features	WOR (Ring), WOL/WOR (PME), PXE
Controller interface type	Serial ATA
Controller 2nd interface type	UltraDMA 100/66/33
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Motherboard form factor	ATX
Compatible operating systems	Windows Vista/XP/2000
Bundled software	Drivers ASUS PC Probe II ASUS Update NVIDIA MediaShield RAID
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	193 mm
Width	305 mm
