Asus P11C-M/4L User Manual

ix
Processor Support / System Bus
1 x Socket LGA1151
Intel
®
Xeon
®
processor E-21xxx product family
(95W)
Intel
®
Core™ i3 processors
Intel
®
Pentium™ processors
Intel
®
Celeron™ processors
Core Logic
Intel
®
C242 Chipset
Form Factor
Micro ATX, 9.6 in. x 9.6 in.
ASUS Features
Fan Speed Control
Rack Ready
(Rack and Pedestal
dual use)
ASUS Control Center
Memory
Total Slots
4 (2 Channels)
Voltage
1.2V
Capacity
Maximum up to 64GB
Memory Type
DDR4 2666/2400 ECC/non-ECC UDIMM
Memory Size
16GB, 8GB, 4GB
Expansion
Slots
(follow SSI
Location
number)
Total PCI/PCI-E Slots
2
Slot Location 1
-
Slot Location 2
-
Slot Location 3
-
Slot Location 4
-
Slot Location 5
-
Slot Location 6
1 x PCI-E x16 (x16 Gen3 link)*
* PCIe slot 6 shares bandwidth with PCIe slot 7, when PCIe
slot 7 is occupied PCIe slot 6 will run in x8 mode.
Slot Location 7
1 x PCI-E x8 (x8 Gen3 Link)
Storage
SATA Controller
Intel
®
C242:
6 x SATA 6Gb/s ports* with
2 x M.2 (NGFF 22110/2280/2260/2242,
(PCI-E Gen3 x2 link or SATA signal)
Intel
®
RSTe (Windows & Linux)
(Support software RAID 0, 1, 10 & 5)
* The gray SATA port will disabled when M.2 is set to SATA
signal
SAS Controller
Optional kits:
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID
card
P11C-M/4L Specications Summary
(continued on the next page)

Asus P11C-M/4L Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2400, 2666 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Pentium, Intel Xeon
USB 2.0 connectors	1
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Component for	PC
Motherboard chipset	Intel C242
Audio output channels	- channels
Motherboard form factor	micro ATX
BIOS type	-
Graphics card	AST2500
Storage temperature (T-T)	10 - 35 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	20 - 90 %
LAN controller	Intel® I210-AT
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	244 mm
