P8B-E/4L specications summary
Processor Support / System Bus
1 x Socket LGA1155
Intel
®
Xeon
®
E3-1200 Processor Family
Intel
®
Core™ i3-2100 Processor Family
Core Logic
Intel
®
C204 Chipset
Form Factor
ATX, 12” x 9.6”
ASUS Features Fan Speed
Control
V
Rack Ready
(Rack and
Pedestal dual
use)
V
ASWM
V
Memory Total Slots
4 (2 Channels)
Capacity
Maximum up to 32GB
Memory Type
DDR3 1066/1333 ECC UDIMM
Expansion
Slots
(follow SSI
Location #)
Total PCI/PCI-X/
PCI-E Slots
6
Slot Location 1
1 x PCI 32bit/33 MHz
Slot Location 2
1 x PCI 32bit/33 MHz
Slot Location 3
1 x PCI-E x8 (Gen2 x4 link)
Slot Location 4
1 x PCI-E x16 (Gen 2 x8 link)
Slot Location 5
1 x PCI 32bit/33 MHz
Slot Location 6
1 x PCI-E x16 Gen 2 (x16 link)
(Auto switch to x8 link if slot 4 is occupied)
Additional Slot
1
1 x PIKE Slot for Storage expansion
Storage SATA Controller Intel
®
C204:
- 2 x SATA 6Gb/s ports
- 4 x SATA 3Gb/s ports
- Intel
®
Rapid Storage Technology (RST) supports
software RAID 0, 1, 10 & 5 (Windows)
LSI MegaRAID driver:
- Supports software RAID 0, 1 & 10 (Windows &
Linux)
SAS Controller
Optional:
ASUS PIKE 2108 8-port SAS2 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card
ASUS PIKE 2008 8-port SAS2 6G RAID card
ASUS PIKE 1068E 8-port SAS RAID card
ASUS PIKE 6480 8-port SAS RAID card
Networking LAN
4 x Intel 82574L
1 x Mgmt LAN
Graphic VGA
Aspeed AST2050 + 16MB VRAM
(continued on the next page)

Asus P8B-E/4L Specifications

General

Microphone in	No
Serial ports quantity	0
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 2.0 connectors	3
Chassis intrusion connector	Yes
PCI Express slots version	2.0
Memory channels	Dual-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
PCI Express slots quantity	6
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2050
On-board graphics card memory	16 MB
Parallel processing technology support	Not supported
Certification	FCC, CFR47 15, B, CE, EN55022, EN55024, C
Component for	Server
Motherboard chipset	Intel® C204
Motherboard form factor	ATX
Cables included	SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor number of cores supported	2, 4

Weight and Dimensions

Depth	304.8 mm
Width	243.8 mm
