ASUS P8B-E/4L 4-21
4.5.10 ME Subsystem
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
ME Subsystem Help
Intel ME Subsystem Conguration
ME Subsystem [Disabled]
USB transfer time-out [20 sec]
Allows you to select the USB transfer time-out value.
Conguration options: [1 sec] [5 sec] [10 sec] [20 sec]
Device reset time-out [20 sec]
Allows you to select the USB device reset time-out value.
Conguration options: [10 sec] [20 sec] [30 sec] [40 sec]
Device power-up delay [Auto]
Conguration options: [Auto] [Manual]
Device power-up delay in seconds [XX]
This item appears only when you set the
Device power-up delay
item to [manual].
Use the <+> and <-> keys to adjust the value. The values range from 1 to 40 with a
one-second interval.
ME Subsystem [Disabled]
Allows you to enable or disable the Intel Management Engine (Intel ME) Subsystem
that performs various tasks while the system is in sleep, during the boot process
and when the system is running. Conguration options: [Enabled] [Disabled]
 
The Onboard Devices Conguration menu items allow you to change the advanced
settings for onboard devices.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Launch Intel PXE OpROM
INTEL W82574L OpROM1 [PXE]
INTEL W82574L OpROM2 [PXE]
INTEL W82574L OpROM3 [Disabled]
INTEL W82574L OpROM4 [Disabled]
Serial Port 1 Conguration
Serial Port 2 Conguration
Parallel Port Conguration

Asus P8B-E/4L Specifications

General

Microphone in	No
Serial ports quantity	0
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 2.0 connectors	3
Chassis intrusion connector	Yes
PCI Express slots version	2.0
Memory channels	Dual-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
PCI Express slots quantity	6
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2050
On-board graphics card memory	16 MB
Parallel processing technology support	Not supported
Certification	FCC, CFR47 15, B, CE, EN55022, EN55024, C
Component for	Server
Motherboard chipset	Intel® C204
Motherboard form factor	ATX
Cables included	SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor number of cores supported	2, 4

Weight and Dimensions

Depth	304.8 mm
Width	243.8 mm
