Asus P8B-E/4L User Manual

4-18 Chapter 4: BIOS setup
4.5.5 North Bridge
The North Bridge is built in the CPU.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Low MMIO resources align at
64MB/1024MB
Memory Information
TOTAL Memory 1024 MB
DIMM_A0 0 MB (DDR3 1333)
DIMM_A1 1024 MB (DDR3 1333)
DIMM_B0 0 MB (DDR3 1333)
DIMM_B1 0 MB (DDR3 1333)
Low MMIO Align [64M]
DMI Gen2 [Enabled]
VT-d [Disabled]
Initate Graphic Adapter [PEG/PCI]
Low MMIO Align [64M]
Allows you to select the options for the Low MMIO Align.
Conguration options: [64M] [1024M]
DMI Gen2 [Enabled]
Allows you to enable or disable the DMI Gen2.
Conguration options: [Disabled] [Enabled]
VT-d [Disabled]
Allows you to enable or disable the VT-d.
Conguration options: [Disabled] [Enabled]
Initiate Graphic Adapter [PEG/PCI]
Allows you to decide which graphics controller to use as the primary boot device.
Conguration options: [PCI/PEG] [PEG/PCI]
4.5.6 South Bridge
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Enabled/disabled the High
Precision Event Timer.
SB Chipset Conguration
High Precision Event Timer Conguration
High Precision Timer [Enabled]
High Precision Timer [Enabled]
Allows you to enable or disable the High Precision Event Timer.
Conguration options: [Enabled] [Disabled]

Asus P8B-E/4L Specifications

General

Microphone in	No
Serial ports quantity	0
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 2.0 connectors	3
Chassis intrusion connector	Yes
PCI Express slots version	2.0
Memory channels	Dual-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
PCI Express slots quantity	6
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2050
On-board graphics card memory	16 MB
Parallel processing technology support	Not supported
Certification	FCC, CFR47 15, B, CE, EN55022, EN55024, C
Component for	Server
Motherboard chipset	Intel® C204
Motherboard form factor	ATX
Cables included	SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor number of cores supported	2, 4

Weight and Dimensions

Depth	304.8 mm
Width	243.8 mm
