4-26 Chapter 4: BIOS setup
4.6 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
CPU Temperature(PECI) [ +35ºC/ +94ºF]
MB Temperature [ +35ºC/ +94ºF]
TR1 Temperature [ N/A ]
CPU FAN1 Speed [ 1305 RPM]
FRNT FAN1 Speed [ N/A ]
FRNT FAN2 Speed [ N/A ]
FRNT FAN3 Speed [ N/A ]
REAR FAN1 Speed [ N/A ]
FAN Speed Control [Generic Mode]
VCORE1 [ +1.200 V ]
+3.3V [ +3.360 V ]
+5V [ +5.160 V ]
+12V [ +12.384 V ]
VBAT [ +3.408 V ]
+3VSB [ +3.422 V ]
+1.5V [ +1.496 V ]
CPU/MB/TR1 Temperature [xxx�C/xxx�F][xxx�C/xxx�F]
The onboard hardware monitor automatically detects and displays the CPU and
motherboard component temperatures. Select Ignore if you do not wish to display
the detected temperatures.
CPU FAN1 Speed; FRNT FAN1–3 Speed; REAR FAN1 Speed
[xxxx RPM] or [Ignore] / [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans, and rear fan in rotations per minute (RPM). If the fan is not
connected to the motherboard, the eld shows
N/A
.
Fan Speed Control [Generic Mode]
Allows you to congure the ASUS Smart Fan feature that smartly adjusts the fan
speeds for more efcient system operation.
Conguration options: [Full Speed Mode] [High Density Mode] [Generic Mode]
[Whisper Mode]
VCORE1 Voltage, 3.3V Voltage, +5V Voltage, +12V Voltage,
VBAT Voltage, +3VSB Voltage, +1.5V ICHVoltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators. Select
Ignore
if you do not want to detect this item.

Asus P8B-E/4L Specifications

General

Microphone in	No
Serial ports quantity	0
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 2.0 connectors	3
Chassis intrusion connector	Yes
PCI Express slots version	2.0
Memory channels	Dual-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
PCI Express slots quantity	6
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2050
On-board graphics card memory	16 MB
Parallel processing technology support	Not supported
Certification	FCC, CFR47 15, B, CE, EN55022, EN55024, C
Component for	Server
Motherboard chipset	Intel® C204
Motherboard form factor	ATX
Cables included	SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor number of cores supported	2, 4

Weight and Dimensions

Depth	304.8 mm
Width	243.8 mm
