2-26 ASUS P8H61 EVO
2.7 Boot menu
The Boot menu items allow you to change the system boot options.
2.7.1 Bootup NumLock State [On]
[On] Sets the power-on state of the NumLock to [On].
[Off] Sets the power-on state of the NumLock to [Off].
2.7.2 Full Screen Logo [Enabled]
[Enabled] Enables the full screen logo display feature.
[Disabled] Disables the full screen logo display feature.
Set this item to [Enabled] to use the ASUS MyLogo 2™ feature.
Post Report [5 sec]
This item appears only when the Full Screen Logo item is set to [Disabled] and allows you
to set the waiting time for the system to display the post report. Conguration options: [1 sec]
[2 sec] [3 sec] [4 sec] [5 sec] [6 sec] [7 sec] [8 sec] [9 sec] [10 sec] [Until Press ESC]
2.7.3 Wait For ‘F1’ If Error [Enabled]
[Disabled] Disables this function.
[Enabled] The system waits for the <F1> key to be pressed when error occurs.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Select the keyboard NumLock state
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
EFI BIOS Utility - Advanced Mode
Bootup NumLock State On
Full Screen Logo Enabled
Wait for ‘F1’ If Error Enabled
Option ROM Messages Force BIOS
Setup Mode EZ Mode
Boot Option Priorities
Boot Option #1 SATA: xxxxxxx
Boot Option #2 SATA: xxxxxxx
> CD/DVD ROM Drive BBS Priorities
> Hard Drive BBS Priorities
Boot Override
> SATA: xxxxxxxxxxxx
> SATA: xxxxxxxxxxxx

Asus P8H61 EVO Specifications

General

Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	4 x DIMM
Memory Type	DDR3
Maximum Memory	32GB
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1600/1333/1066
Storage Interface	4 x SATA 3Gb/s
Form Factor	ATX
Audio Chipset	Realtek ALC887
Audio Channels	8 Channels
RAID Support	No
Multi-GPU Support	No
Expansion Slots	2 x PCIe 2.0 x1, 3 x PCI
LAN	Realtek 8111E
USB Ports	12 x USB 2.0
