Asus P8H61 EVO User Manual

ix
P8H61 EVO specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
Second Generation Core™ i7 /
Core™ i5 / Core™ i3 Processors
Supports 32nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H61 Express Chipset
Memory 4 x 240-pin DIMM sockets support maximum 16GB unbuffered
non-ECC DDR3 1333 / 1066MHz memory modules
Dual-channel memory architecture
Support Intel
®
Extreme Memory Prole (XMP)
* Refer to www.asus.com for the Memory QVL (Qualied
Vendors Lists).
** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system
memory if you are using a Windows
®
32-bit operating system.
Expansion slots 1 x PCI Express 2.0 x16 slot
2 x PCI Express 2.0 x1 slots
3 x PCI slots
Storage Intel
®
H61 Express Chipset:
- 4 x Serial ATA 3.0Gb/s connectors
ASMedia SATA 6.0Gb/s controller:
- 2 x Serial ATA 6.0Gb/s connectors
LAN Realtek
®
8111E Gigabit LAN controller
Audio ALC887 8-channel High Denition Audio CODEC supports:
- Jack-detection, Multi-streaming, and Front Panel Jack-
Retasking
- Optical S/PDIF out ports at mid-board and back I/O
USB ASMedia
®
1042 USB 3.0 controller:
- 4 x USB 3.0/2.0 ports (2 ports at mid-board, 2 ports at the back
panel [blue])
Intel
®
H61(B3) Express Chipset:
- 10 x USB 2.0/1.1 ports (4 ports at mid-board, 6 ports at the
back panel)

Asus P8H61 EVO Specifications

General

Brand	Asus
Model	P8H61 EVO
Category	Motherboard
Language	English
