ASUS Q87T
2-27
2.6.3 PCH Conguration
PCI Express Conguration
DMI Link ASPM Control [Auto]
Allows you to control the Active State Power Managemennt on both NB and SB side of
the DMI Link. Conguration options: [Auto] [Enabled] [Disabled]
ASPM Support [Disabled]
Allows you to set the ASPM support. Conguration options: [Disabled] [Auto] [L0s] [L1]
L0sL1].
PCIe Speed [Auto]
Allows you to select the PCI Express port speed. Conguration options: [Auto] [Gen1]
[Gen2]
Intel
®
Rapid Start Technology
Intel
®
Rapid Start Technology [Disabled]
Allows you to enable or disable Intel
®
Rapid Start Technology. Conguration options:
[Enabled] [Disabled]
The following items appear only when you set the Intel
®
Rapid Start Technology to
[Enabled].
Entry on S3 RTC Wake [Enabled]
The system automatically wakes up and set to Rapid Start Technology S4
mode. Conguration options: [Enabled] [Disabled
Entry After [x]
Allows you to set the wake-up time.The values range from 0 (immediately)
to 120.
Active Page Threshold Support [Enabled]
The system automatically set itself to sleep when the partition size is
not enough for Rapid Start Technology to work. Conguration options:
[Enabled] [Disabled]
Active Memory Threshold [0]
Key in the value for the additional partition size for Rapid Start Technology
to work.
Ensure that the caching partition size is larger than the total memory size.
Hybrid Hard Disk Support [Disabled]
Allows you to enable or disable hybrid hard disk support. Conguration
options: [Enabled] [Disabled]
