Q87T specications summary
(continued on the next page)
CPU LGA1150 socket for Intel
®
4th Generation Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports 22nm CPU*
Supports Intel
®
Turbo Boost Technology 2.0**
* Up to 65W Thermal Design Power support for Intel
®
standard thin mini-ITX
heatsink. Up to 84W Thermal Design Power support for standard 1150/1155
heatsink.
** Intel
®
Turbo Boost Technology 2.0 support depends on the CPU type.
*** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
Q87 Express Chipset
Memory 2 x SO-DIMMs, max. 16GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
* Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
** When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics Integrated graphics processor
Multi-VGA output support: DisplayPort / eDP / HDMI / LVDS*
- Supports DisplayPort 1.2 / eDP with max. resolution of 4096 x
2160@24Hz / 3840 x 2160 @60Hz
- Supports HDMI with max. resolution of 4096 x 2160 @24Hz / 2560 x
1600 @60Hz
- Supports LVDS with max.resolution of 1920 x 1200 @60Hz
Maximum shared memory of 1024 MB
*LVDS and eDP share the same video output. An onboard header is available to
switch output.
Expansion slots 1 x PCI Express 3.0/2.0 x4 slot
1 x mini PCIe (full length, with mSATA support)
1 x mini PCIe (half length)
*mSATA shares the same slot with the full-length mini PCIe. When an mSATA card
is inserted, the mini PCIe slot is not available.
Package contents
Check your motherboard package for the following items.
Motherboard ASUS Q87T motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables, 1 x SATA power cable
Accessories 2 x I/O Shield (1 x mini-ITX, 1 x thin mini-ITX)
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.

Asus Q87T Specifications

General

Brand	Asus
Model	Q87T
Category	Motherboard
Language	English
