Asus ROG STRIX Z590-E GAMING Series User Manual

ROG STRIX Z590-E GAMING Series
1-11
Chapter 1
6. Power connectors
These Power connectors allow you to connect your motherboard to a power supply.
The power supply plugs are designed to fit in only one orientation, find the proper
orientation and push down firmly until the power supply plugs are fully inserted.
• DO NOT connect the 4-pin power plug only, the motherboard may overheat under
heavy usage.
• Ensure to connect the 8-pin power plug, or connect both the 8-pin and 4-pin power
plugs.
• For a fully configured system, we recommend that you use a power supply unit
(PSU) that complies with ATX 12V Specification 2.0 (or later version) and provides a
minimum power of 350 W.
• We recommend that you use a PSU with a higher power output when configuring a
system with more power-consuming devices. The system may become unstable or
may not boot up if the power is inadequate.
• If you want to use two or more high-end PCI Express x16 cards, use a PSU with
1000W power or above to ensure the system stability.

Asus ROG STRIX Z590-E GAMING Series Specifications

General

Chipset	Intel Z590
CPU Socket	LGA 1200
Memory Slots	4 x DIMM
Maximum Memory	128GB
Memory Type	DDR4
Audio	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Form Factor	ATX
Bluetooth	Bluetooth 5.2
RGB Lighting	Aura Sync RGB
Memory Speed	5333MHz (OC)
PCIe Slots	1 x PCIe 3.0 x16
Storage	3 x M.2, 6 x SATA 6Gb/s
USB Ports	4 x USB 2.0
Networking	Intel 2.5Gb Ethernet
