2-18
Chapter 2: Basic Installation
Chapter 2
2.1.9 Front I/O connector
USB 3.2 Gen 2x2 Type-C
®
To install USB 3.2 Gen 2x2 Type-C®
connector
To install the front panel connector
This connector will only fit in one
orientation. Push the connector until it
clicks into place.
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector
USB 3.2 Gen 1
To install USB 3.2 Gen 1 connector

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus ROG STRIX Z590-E GAMING Series and is the answer not in the manual?

Asus ROG STRIX Z590-E GAMING Series Specifications

General IconGeneral
ChipsetIntel Z590
CPU SocketLGA 1200
Memory Slots4 x DIMM
Maximum Memory128GB
Memory TypeDDR4
AudioROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Form FactorATX
BluetoothBluetooth 5.2
RGB LightingAura Sync RGB
Memory Speed5333MHz (OC)
PCIe Slots1 x PCIe 3.0 x16
Storage3 x M.2, 6 x SATA 6Gb/s
USB Ports4 x USB 2.0
NetworkingIntel 2.5Gb Ethernet
