Asus ROG STRIX Z590-E GAMING Series User Manual

1-18
Chapter 1: Product Introduction
Chapter 1
15. Front Panel Audio header
The Front Panel Audio header is for a chassis-mounted front panel audio I/O module
that supports HD Audio. Connect one end of the front panel audio I/O module cable to
this header.
We recommend that you connect a high-definition front panel audio module to this
connector to avail of the motherboard’s high-definition audio capability.
14. CPU Over Voltage jumper
The CPU Over Voltage jumper allows you to set a higher CPU voltage for a flexible
overclocking system (depending on the type of the installed CPU). Set to pins 2-3 to
increase the CPU voltage setting, or set to pins 1-2 to use the default CPU voltage
setting.

Asus ROG STRIX Z590-E GAMING Series Specifications

General

Chipset	Intel Z590
CPU Socket	LGA 1200
Memory Slots	4 x DIMM
Maximum Memory	128GB
Memory Type	DDR4
Audio	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Form Factor	ATX
Bluetooth	Bluetooth 5.2
RGB Lighting	Aura Sync RGB
Memory Speed	5333MHz (OC)
PCIe Slots	1 x PCIe 3.0 x16
Storage	3 x M.2, 6 x SATA 6Gb/s
USB Ports	4 x USB 2.0
Networking	Intel 2.5Gb Ethernet
