Asus WL-520gU User Manual

21
Chapter 4: Conguring via the web GUI WL-520GU
4
Conguring via
the web GUI
Conguring via the web GUI
The router’s web graphics user interface (web GUI) allows you to congure these
features: Network Map, EZQoS Bandwidth Management, and other Advanced
Setting.
To congure via the web GUI:
1. After setting up a wired or wireless connection, launch a web browser. The
login page is automatically launched.
Note: You may also manually key in the router’s default IP address (192.168.1.1) to launch the
router’s web interface.
2. On the login page, key in the default user name (admin) and password
(admin).

Asus WL-520gU Specifications

General

Bandwidth	2.4 GHz
xDSL connection	No
Dimensions (WxDxH)	164 x 116.5 x 31 mm
Power requirements	+5V; 2A
USB ports quantity	1
Filtering description	URL
Maximum data transfer rate	0.125 Gbit/s
Compatible operating systems	Windows 2000/XP/Vista
Full duplex	Yes
VPN support	IPSec, PPTP, L2TP
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Channels quantity	13 channels
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA-PSK, WPA2
Authentication method	802.1x RADIUS, MAC
Storage temperature (T-T)	-30 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	50 - 90 %
LED indicators	LAN, WAN

Weight and Dimensions

Weight	262 g
