Asus WL-520gU User Manual

25
Chapter 4: Conguring via the web GUI WL-520GU
Upgrading the rmware
Note: Download the latest rmware from the ASUS website at http://www.asus.com
To upgrade the rmware:
1. Click Advanced Setting from the navigation menu at the left side of your
screen.
2. Under the Administration menu, click Firmware Upgrade.
3. In the New Firmware File eld, click Browse to locate the new rmware on your
computer.
4. Click Upload. The uploading process takes about three minutes.
Note: If the upgrade process fails, the wireless router automatically enters the emergency or
failure mode and the power LED indicator at the front panel ashes slowly. To recover or restore
the system, use the Firmware Restoration utility. For more details on this utility, refer to the
section Firmware Restoration in Chapter 5 of this user manual.

Asus WL-520gU Specifications

General

Bandwidth	2.4 GHz
xDSL connection	No
Dimensions (WxDxH)	164 x 116.5 x 31 mm
Power requirements	+5V; 2A
USB ports quantity	1
Filtering description	URL
Maximum data transfer rate	0.125 Gbit/s
Compatible operating systems	Windows 2000/XP/Vista
Full duplex	Yes
VPN support	IPSec, PPTP, L2TP
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Channels quantity	13 channels
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA-PSK, WPA2
Authentication method	802.1x RADIUS, MAC
Storage temperature (T-T)	-30 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	50 - 90 %
LED indicators	LAN, WAN

Weight and Dimensions

Weight	262 g
