Asus Z9PE-D8 WS User Manual

5-42 Chapter 5: RAID conguration
4. Use the up or down arrow key to move the selection bar and press <Enter>
to congure further RAID settings.
RAID Level: Select a RAID Level. Conguration options: [RAID 0] [RAID 1]
[RAID 10] [HyperDuo]
Stripe Size: Species the size of single data block on the virtual disk. In
general, a larger stripe size is recommended for applications requiring large
data transfers such as audio, video, and graphics. A smaller stripe size is
better for applications with content in much smaller size, such as e-mails and
documents.
Conguration options: [32K] [64K]
Gigabyte Rounding: In the event of a single physical disk failure in a RAID
1 virtual disk, Gigabyte Rounding allows the replacement physical disk to be
of a size slightly smaller than the existing physical disk. The capacity of the
rebuilt virtual disk equals to the size of the smaller physical disk included in
the RAID 1 array. The conguration options represent the tolerance value of
drive capacity difference.
Conguration options: [None] [1G] [10G]
Name: Enter a name with 1–10 letters (no special characters) for the RAID
array.
5. Move the selection bar to Next and press <Enter>. The following warning
message appears:
Do you want to create this virtual disk ?
Yes No
Create Virtual Disk
Press <Y> to create the RAID array, or press <N> to cancel. The new RAID
array appears under Virtual Disks, as shown in the image below.
Marvell BIOS Setup (c) 2011 Marvell Technology Group Ltd.
Congure->Select free disksCreate Virtual Disk
Help
Virtual disk congurations.
ENTER: Select F10: Exit/Save ESC: Return
HBA 0: Marvell 0
├ Virtual Disks
└ Free Physical Disks
* ├ PD 0: ST3160812AS
* └ PD 8: ST3160812AS
RAID Level : RAID 0
Max Size(MB) : 305253
Stripe Size : 64KB
Gigabyte Rounding : 1G
Quick Init : Yes
Name : Default
Threshold(%) : 90
Next
▶ ▶

Asus Z9PE-D8 WS Specifications

General

PS/2 ports quantity	1
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 2.0 connectors	4
Chassis intrusion connector	Yes
PCI Express x16 slots	7
Memory channels	Quad-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	256 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133 MHz
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
Parallel processing technology support	4-Way SLI, Quad-GPU CrossFireX
Component for	PC
Motherboard chipset	Intel® C602
Audio output channels	7.1 channels
Motherboard form factor	SSI EEB
System bus rate	8 GT/s
Processor manufacturer	Intel

Weight and Dimensions

Depth	330 mm
Width	305 mm
