6. Press <F10>. The following warning message appears:
Press <Y> to save the RAID setting and exit the Marvell RAID utility.
Do you want to exit from Marvell BIOS Setup?
Yes No
Exit
5.5.2 Delete an existing RAID Array
1. Select the RAID array to delete and press <Enter>. Select Delete and press
<Enter>.
Marvell BIOS Setup (c) 2011 Marvell Technology Group Ltd.
Help
Delete the selected virtual disk.
ENTER: Operation F10: Exit/Save ESC: Return
HBA 0: Marvell 0
├ Virtual Disks
│ └ VD 0: New_VD
│ ├ PD 0: ST3160812AS
│ └ PD 8: ST3160812AS
└ Free Physical Disks
ID : 0
Name : New_VD
Status : Functional
Stripte Size : 64K
RAID Mode : RAID0
Size : 304128MB
BGA Status : N/A
Number of PDs : 2
Members : 0 8
▶ ▶
Topology
Information
[Delete]
Marvell BIOS Setup (c) 2011 Marvell Technology Group Ltd.
Help
Marvell RAID on chip controller.
ENTER: Operation F10: Exit/Save ESC: Return
HBA 0: Marvell 0
├ Virtual Disks
│ └ VD 0: New_VD
│ ├ PD 0: ST3160812AS
│ └ PD 8: ST3160812AS
└ Free Physical Disks
Vendor ID : 1B4B
Device ID : 9130
Revision ID : B1
BIOS Version : 1.0.0.1028
Firmware Version: 2.2.0.1105
PCIe Speed Rate : 5.0Gbps
Congure SATA as: AHCI Mode
▶ ▶
Topology
Information

Asus Z9PE-D8 WS Specifications

General

PS/2 ports quantity	1
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 2.0 connectors	4
Chassis intrusion connector	Yes
PCI Express x16 slots	7
Memory channels	Quad-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	256 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133 MHz
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
Parallel processing technology support	4-Way SLI, Quad-GPU CrossFireX
Component for	PC
Motherboard chipset	Intel® C602
Audio output channels	7.1 channels
Motherboard form factor	SSI EEB
System bus rate	8 GT/s
Processor manufacturer	Intel

Weight and Dimensions

Depth	330 mm
Width	305 mm
