Asus Z9PE-D8 WS User Manual

ASUS Z9PE-D8 WS 4-21
Memory Conguration
Support for Compatibility
Revision ID(CRID)
Functionality mentioned in
Sandybridge bios spec
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Compatibility RID [Enabled]
Memory Conguration
Total Memory 16384 MB (DDR3)
Current Memory Mode Independent
Currently Memory Speed 1333 MHz
Mirroring Not Possible
Sparing Not Possible
Memory Mode [Independent]
Numa [Enabled]
DDR Speed [Auto]
Channel Interleaving [Auto]
Rank Interleaving [Auto]
Patrol Scrub [Disabled]
Demand Scrub [Enabled]
Data Scrambling [Enabled]
Device Tagging [Disabled]
Thermal Throttling [CLTT]
Enable High Temp. [Disabled]
Allow 2x Refresh [Enabled]
Altitude [300 M]
Memory HOT sensor support [Enabled]
DIMM Information
Compatibility RID [Enabled]
Supports compatibility revision ID (CRID) functionality mentioned in Sandybridge
BIOS spec.
Conguration options: [Enabled] [Disabled]
Memory Mode [Independent]
Select the mode for memory initializaton.
Conguration options: [Independent]
Numa [Enalbled]
Allows you to disable or enable Non Uniform Memory Access.
Conguration options: [Enabled] [Disabled]
DDR Speed [Auto]
This item allows you to congure force DDR speed.
Conguration options: [Auto] [Force DDR3 800] [Force DDR3 1066] [Force
DDR3 1333] [Force DDR3 1600] [Force DDR3 1866] [Force DDR3 2133] [Force
DDR3 2400] [Force DDR3 2666]
Channel Interleaving [Auto]
Select different channel interleaving setting.
Conguration options: [Auto] [1 Way] [2 Way] [3 Way] [4 Way]

Asus Z9PE-D8 WS Specifications

General

PS/2 ports quantity	1
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 2.0 connectors	4
Chassis intrusion connector	Yes
PCI Express x16 slots	7
Memory channels	Quad-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	256 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133 MHz
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
Parallel processing technology support	4-Way SLI, Quad-GPU CrossFireX
Component for	PC
Motherboard chipset	Intel® C602
Audio output channels	7.1 channels
Motherboard form factor	SSI EEB
System bus rate	8 GT/s
Processor manufacturer	Intel

Weight and Dimensions

Depth	330 mm
Width	305 mm
