OVERVIEW
Equipment description
The illustration gives an overview of the main parts
and components of the hydraulic attachment. Actual
details may differ.
CC 1700 U
F
G
H
I
J
K
L
M
N
O
A
B
C
D
E
CC 1700 S
F
G
H
I
J
K
L
M
N
A
B
C
D
E
A. Cutter blades
B. Cutter jaw (double)
C. Four-point bearing
D. Connection function »Turn«
E. Connection »A« function »Open«
F. Adapter plate (not supplied with the hydraulic
demolition cutter)
G. Connection »B« function »Close«
H. Connection function »Turn«
I. Upper part
J. Hydraulic cylinder
K. Housing
L. Cylinder pin
M. Main bearing pin
N. Cutter jaw (single)
O. Tip of tooth
15© 2015 Construction Tools GmbH | No. 3390 5141 01 | 2015-11-16
Original instructions
OVERVIEWCC 1700 U, 1700 S
