Atlas Copco G 7 User Manual

9 Technical data
9.1 Electric cable size
Attention
Local regulations remain applicable if they are stricter than the values proposed below.
The voltage drop must not exceed 5 % of the nominal voltage. It may be necessary to
use cables of a larger size than those stated to comply with this requirement.
Recommended cable size
Cable size, IEC
Voltage
(V)
Frequency
(Hz)
Cable size
IEC G 2 G 3 G 4 G 5 G 7
230/1 50
4 mm
2
- - - -
230/3 50
1.5 mm
2
2.5 mm
2
4 mm
2
4 mm
2
6 mm
2
380/3 60
0.75 mm
2
-
1.5 mm
2
2.5 mm
2
4 mm
2
400/3 50
0.75 mm
2
1 mm
2
1.5 mm
2
2.5 mm
2
4 mm
2
Cable size, UL/CSA
Voltage
(V)
Frequency
(Hz)
Cable size
UL/CSA G 2 G 4 G 5 G 7
230/1 60 AWG10 AWG8 AWG8 -
208/3 60 AWG12 AWG10 AWG8 AWG8
230/3 60 AWG14 AWG10 AWG10 AWG8
460/3 60 AWG14 AWG14 AWG14 AWG12
575/3 60 AWG14 AWG14 AWG14 AWG14
Instruction book
80 2920 7199 10

Atlas Copco G 7 Specifications
