4.4. Pump data
Table 2 Pump data
Description
Unit
GVS
16A
GVS
25A
GVS
40A
GVS
60A
GVS
100A
GVS
200A
GVS
220A
GVS
300A
GVS
470A
GVS
630A
Volumetric flow
rate 50 Hz
m³/h 16 25 44 59 97.5 180 200 280 470 700
cfm 9.4 14.5 25.9 34.8 57.4 106 117 165 277 412
Volumetric flow
rate 60 Hz
m³/h 18.7 29 53 71 117 220 240 340 570 840
cfm 11 17.1 31.2 41.8 68.9 130 141 200 366 494
Pumping speed
versus pressure
Refer to Performance curves on page 34.
Ultimate pressure
without gas ballast
mbar(a) 0.5 0.5 0.5 0.5 0.5 0.1 0.1 0.1 0.1 0.1
torr
(mmHg)
0.4 0.4 0.4 0.4 0.4 0.08 0.08 0.08 0.08 0.08
Ultimate pressure
with open gas
ballast
mbar(a) 1.5 1.5 1.5 1.5 1.5 0.7 0.7 0.7 0.7 0.7
torr
(mmHg)
1.1 1.1 1.1 1.1 1.1 0.5 0.5 0.5 0.5 0.5
Ultimate pressure
without gas ballast
for oxygen
versions
mbar(a) N/A N/A N/A 1 1 1 1 1 1 1
torr
(mmHg)
N/A N/A N/A 0.75 0.75 0.75 0.75 0.75 0.75 0.75
Ultimate pressure
with open gas bal-
last for oxygen
versions
mbar(a) N/A N/A N/A 2.5 2.5 1.5 - 1.5 1.5 1.5
torr
(mmHg)
N/A N/A N/A 1.9 1.9 1.2 - 1.2 1.2 1.2
Nominal motor
power 50 Hz
kW 0.75 0.75 1.1 1.5 2.2 4 4.5 5.5 9.2 15
hp 1 1 1.5 2.2 3 6 6 7.5 12 20
