Atlas Copco XAS 67 Dd C3 APP User Manual

- 55 -
Before starting, open the air outlet valve(s) (AOV)
and push circuit breaker button (F1) once (open hood
first). Circuit breaker button should now be in
position B.
STARTING PROCEDURE (WITHOUT COLD START)
Reference Name
P1 Digital hour meter
F1 Circuit breaker button
PG Working pressure gauge
H1 Temperature alarm lamp (red)
H2 General alarm lamp (red)
S1 Start switch
S4 Lamp test button
(P1) (PG) (H1)
(H2)
(S1)
(S4)
(F1)
The control panel indicates receiver
pressure (PG) and accumulated
operating hours (P1).
The circuit breaker button is a
protection against unintended starting
of the compressor.
A
B
(F1)

Atlas Copco XAS 67 Dd C3 APP Specifications

General

Brand	Atlas Copco
Model	XAS 67 Dd C3 APP
Category	Air Compressor
Language	English
