Reference Description
44 Net mass of a compressor without a motor
45 700 kg should be added in case of an oversized motor or motor with supply voltage >
690 V
1540 lb should be added in case of an oversized motor or motor with supply voltage >
690 V
46 Cooling air outlet
47 Automatic drain of dryer inlet G 1/2" (female)
48 Automatic low load drain drain for optional low load dryer feature
49 Cooling air inlet
50 Left side view
51 Center of gravity Z 160-275
52 Center of gravity Z 250/315 VSD
53 Left side view (for hot air version)
54 Hot air version
55 Standard version
56 Water in/out DN 50 PN 16 acc. DIN 2633 (Scale 1:5)
57 700 kg should be added in case of a high ambient temperature compressor or an
oversized motor or a motor with supply voltage > 690 V
1540 lb should be added in case of a high ambient temperature compressor or an
oversized motor or a motor with supply voltage > 690 V
58 Automatic drain of aftercooler G 1/2" (female) (not for hot air version)
59 Automatic drain of regeneration outlet 1, G 1/2" (female)
60 Automatic drain of regeneration outlet 2, G 1/2" (female)
7.2 DIN to JIS adaptor flanges
Application
Compressors used for the Japanese market are connected to an outlet pipe that is manufactured according
to the local JIS standard (Japanese Industrial Standard). To enable the connection between the mounted
DIN flanged compensator and the JIS outlet pipe the compressor comes with a loose DIN to JIS adaptor
flange that should be welded on the Japanese customer's installation.
Instruction book
190 2920 1815 04
