Avigilon 2.0C-H5A-PTZ-DP36 User Manual

Pendant Mount Installation
Camera Package Contents
Note: The pendant wall mount and pendant NPT mount are sold separately.
Ensure the camera package contains the following:
l Avigilon H5A-PTZ Pendant Camera
l T20 star key
l 2 x RJ-45 crimp-on plug
l Audio, external power, and I/O pigtail cable connector
If you are installing the camera with the pendant wall mount, ensure the package includes the following:
l Pendant wall mount (IRPTZ-MNT-WALL1 )
l Mounting template sticker
If you are installing the camera with the NPT mount, ensure the package includes the following:
l NPT mount (IRPTZ-MNT-NPTA1)
l Lock nut
l Thread sealing tape
Installation Steps
Complete the following sections to install the device.
Preparing the Camera for Installation
Note: Be careful not to scratch the dome bubble.
Pendant Mount Installation 16

Avigilon 2.0C-H5A-PTZ-DP36 Specifications

General

Brand	Avigilon
Model	2.0C-H5A-PTZ-DP36
Category	Digital Camera
Language	English
