AVMATRIX HVS0403U User Manual

3
3. SPECIFICATION
CONNECTION
Video In
HDMI type-A ×2, SDI×2
Video Out
HDMI type-A PGM ×2
HDMI type-A Multiview ×1
USB2.0 type C ×1 (Streaming on PC)
Assignable SDI 1~2, HDMI3~4,PGM, Clean PGM, PVW, Color bar, Multiview
Audio In
MIC/ Line level (3.5mm stereo audio) ×2
PC Control Port
LAN×1(For PC remote control)
Media Library
USB type-A ×1(USB disk port for image import and firmware upgrade)
Tally Port
DB-15 ×1
Power In
DC 12V ×1
FUNCTIONS
Transitions
T-Bar/AUTO/ CUT
Effects
Wipe (11×2 patterns)/ Mix/ DIP/ Still(freeze)/ MUTE/ FTB
Layouts
2 styles of Multiview layout (6 windows and status)
Keys
Upstream Key: Luma Key ×1/ Chroma Key ×1/ PIP ×2/ POP
Downstream Key: DSK ×1/ Logo ×1
Audio Mixer
HDMI ×2, SDI×2 and MIC/ Line level ×2;
Audio delay: 0-500ms
Media
Default image: 39 preset patterns
Local image: up to 16 imported images
Capture image: up to 16 captured images
Generators
Pattern generator ×1
Color generators ×2
STANDARDS
HDMI In Format
Support
1080p 60/ 59.94/ 50/ 30/ 29.97/ 25/ 24/ 23.98
1080i 50/ 59.94/ 60
720p 60/ 59.94 /50/ 30/ 25/ 24
576i 50, 576p 50, 480p 59.94/ 60, 480i 59.94/ 60
HDMI PGM Out
1080p 60/ 59.94/ 50/ 48/ 47.95/ 30/ 29.97/ 25/ 24/ 23.98; 1080i 60/ 59.94/ 50
HDMI Multiview Out
1080p 60/ 59.94/ 50/ 48/ 47.95/ 30/ 29.97/ 25/ 24/ 23.98; 1080i 60/ 59.94/ 50
HDMI Color Space
RGB/ YUV
SDI In Format Support
1080p 60/59.94/50/30/29.97/25/24/23.98
1080psF 30/29.97/25/24/23.98
