Baumuller BUM 62 T User Manual

Technical data
Mono Power Unit BUM 62 T 13
Baumüller Nürnberg GmbH 5.99009.03
3 TECHNICAL DATA
3.1 Table of technical data
BUM 62 T - 100 / 130 - ...
Connection voltage (mains)
1)
3 x 400 V
AC
±15% 50 Hz
3 x 460 V
AC
+10% -25% 60 Hz
Supply voltage
2)
+ 24 V
DC
-10% / +20 % (72W)
Continuous input power max. 50 kVA
Rated DC link voltage
3)
540 V
DC
DC link capacity (internal) 1700 µF
DC link capacity (external) max. 500 µF
Cycle time for connect the unit in circuit again
(without additional DC link capacitors)
≥3 min
Output voltage
4)
3 x 0 V
AC
... 3 x (conn. volt. -30 V)
Output frequency
5)
0 Hz. ...300 Hz
Continuous output power
at 4 kHz
10)
max. 62 kVA
Continuous output power
at 8 kHz
10)
max. 50 kVA
Continuous motor power
at 4 kHz
10)
max. 43 kW
Continuous motor power
at 8 kHz
10)
max. 35 kW
Rated output current
6) 7) 8)
at 4 kHz
10)
100 A
Rated output current
6) 7) 8)
at 8 kHz
10)
75 A
Peak output current
6) 7) 9)
at 4 kHz
10)
130 A
Peak output current
6) 7) 9)
at 8 kHz
10)
97 A
Connection power DC link connection 36 kW
External chopper current max. 73 A
Internal chopper resistor -
External chopper resistor ≥ 11 Ω
Application threshold of regenerative resistor 750 V
Ambient temperature range (operation)
11)
min. 0 °C .... max. 55 °C
40 °C (nominal temperature)
Power loss
3)
Connect. (mains)
Supply
1400 W
max. 72 W
Type of protection IP 20
Installation height
12)
max. 1000 m a.m.s.l.
relative humidity 15 % ... 85 % no condensation.
Temperature range for transport - 30 °C ... + 70 °C
Temperature range for storage - 30 °C ... + 70 °C
Dimensions (W x H x D) 264 x 560 x 280 mm
Weight without controller 30 kg
