Beckhoff EL9 Series User Manual

Product overview
EL9xxx56 Version: 3.9
Technical Data
Technical Data EL9400 EL9410
Input voltage 24 V
DC
Output current for E-bus supply 2 A
Power contact voltage 24 V
DC
Power contact current load max. 10 A
Current consumption from E-Bus - -
Electrical isolation 500 V (E-bus/field potential)
Diagnosis no yes, via LED and in the process image
Electrical connection to mounting rail no
PE contact yes
Renewed infeed yes
Connection facility to additional power con-
tact
1
Side by side mounting on Bus Terminals
with power contact
yes
Side by side mounting on Bus Terminals
without power contact
yes
Bit width in the process image - 2 bits (diagnosis)
Configuration no address or configuration settings
Weight approx. 65 g
Permissible ambient temperature range
(during operation)
0°C ... +55°C
Permissible ambient temperature range
(during storage)
-25°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}73]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance
conforms to EN60068-2-6/EN60068-2-27, see Installation instructions [}76] for en-
hanced mechanical load capacity
EMC resistance burst/ESD conforms to EN 61000-6-2/EN 61000-6-4
Protect. class IP 20
Installation pos.
variable, see chapter "Mounting of Passive
Terminals [}83]"
variable
Approval CE
ATEX [}84]
cULus [}86]
Connection EL9400, EL9410
Terminal point Description
Indication No.
+24 V for E-Bus 1 Supply input + 24 V for the E-Bus
+24 V 2 Supply input + 24 V (connected internally with terminal 6 and positive power
contact)
0 V 3 0 V for supply input (connected internally with terminal 7 and negative power
contact)
PE 4 PE (connected internally with terminal 8)
0 V for E-Bus 5 0 V for supply input E-Bus
+24 V 6 Supply input + 24 V (connected internally with terminal 2 and positive power
contact)
0 V 7 0 V for supply input (connected internally with terminal 3 and negative power
contact)
PE 8 PE (connected internally with terminal 4)
