BLUM PRO-CENTER 2000 User Manual

19
Carcase profiles
1. Choose ruler and set stops
• Recommended rulers:
- Standard ruler MZL.2000
- Reversible ruler MZL.2010
a) Standard ruler MZL.2000
• Set stops at intervals desired
b) Reversible ruler MZL.2010
• Clamp down either the right or left
side of ruler. The ruler must simply
be turned over to drill right and left
components. That means higher
accuracy as stops need only be set
once.
• Sets stops at intervals desired
2. Insert drilling head and ruler
• Insert ruler into machine
• Clamp drill bits in drill chucks
2 x 5 mm Ø, clockwise
2 x 5 mm Ø, anti-clockwise
• Insert drilling head at a right angle to
ruler
3. Adjust drilling depth
4. Set worktable to drilling distance
desired
5. Proceed to drill
• Place work piece on worktable and
drill for carcase profiles
Working with MTZ.2880
