BMC G2S BPAP Series User Manual

G2S BPAP Series User Manual V2.1
20 / 43
CAUTIONS!
• Do not position the device where it is difficult to operate the disconnection device.
• To isolate the device from the supply mains, disconnect the plug.
13. Heated Humidifier
The humidifier is available from your home care provider. The humidifier may reduce nasal
dryness and irritation by adding moisture (and heat if applicable) to the airflow.
13.1 Filling the Water Chamber
13.1.1 Removing the Water Chamber
Grab the water chamber, and pull it out of the device, as shown in the figure below.
Fig. 13-1
WARNING!
• Turn the device off and allow approximately 15 minutes for the heater plate and water to
cool.
13.1.2 Filling Water
Open the cap, as shown in Fig. 13-2, and fill the water chamber with approximately 360 ml
of water, as shown in Fig. 13-3. Make sure that the water does not exceed the maximum
water level line.
Fig. 13-2

BMC G2S BPAP Series Specifications

General

IPAP	4-30 cmH2O
EPAP	4-25 cmH2O
Pressure Range	4-30 cmH2O
Rise Time	1-6 levels
Operating Voltage	100-240 V AC, 50/60 Hz
Heated Humidifier	Optional
Data Storage	SD Card
Therapy Mode	S, T
Alarms	Power failure, High pressure, Low pressure, Apnea
Device Type	BPAP (Bi-level Positive Airway Pressure)
Automatic Altitude Adjustment	Automatic
