BMW 3-series convertible User Manual

E93 Complete Vehicle Workbook
65
Rear module
The trunk lid and hardtop lid are integrated into the rear module. The rear module is fastened to the body using a supporting bar structure
with main mount. The rear module weighs about 105 lbs. The trunk lid is equipped with Soft Close Automatic.
Index Explanation Index Explanation
1
Opening hinges for linkage (main pillar)
6
Wiring harness
2
Hardtop lid
7
Rear module linkage
3
Trunk lid
8
Trunk lid damper
4
Tail lights
9
Trunk lid linkage
5
Rear module main mount
