8
E93 Complete Vehicle Workbook
E93 Body Construction
Index Explanation Index Explanation
1
DC 03/04
6
HC 600 C
2
HC 180 BD/HC 220 BD
7
22 Mn B5, Docol 1000 DP
3
HC 260 BD/HC 300 BD
8
Plastics
4
HC 400 TD/HC 380 LAD
9
Other
5
HC 420 LAD
As with all current BMW models, there is an extensive use of high
strength steels.
There is an “intelligent mix” of materials to provide the lightest
possible weight with the best possible strength.
The color illustrations above, demonstrate the distribution of the
materials. For more information, refer to the E93 complete vehicle
reference material in TIS and ICP.
The design of the E93 also allows for an increase in torsional
rigidity over the E46 iC. The chart at the right illustrates these
figures.
Torsional Rigidity E46iC E93
Dynamic 17.5 Hz 19 Hz
Static 11,500 Nm/degree 14,500 Nm/degree
