BMW G 650 Xmoto User Manual

Release the number-plate car-
rier with wire loop 3 and re-
move, working plug 2 with the
cable free.
Installing number-plate
carrier
Manoeuvre the cable into po-
sition, hold the number-plate
carrier in position and push it
up.
Pin 4 engages with an audible
click.
Install four screws 1.
Connect plug 2.
8
95
z Maintenance

BMW G 650 Xmoto Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Max Power	53 hp (39 kW) @ 7, 000 rpm
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Transmission	5-speed
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Engine Type	Single cylinder, four-stroke
Max Torque	60 Nm (44 lb-ft) @ 5, 250 rpm
Front Suspension	45 mm
Front Brake	Single disc, 2-piston caliper
Rear Brake	Single disc, 240 mm, 1-piston caliper
Fuel Capacity	9.5 l
