BMW K 1200 LT Owner's Manual

35
General information and controls
1
B
A
1
Front seat
Adjusting front seat:
•Open the seat (b 34)
– Mover adjuster 1 to the desired
position (arrow)
– The front seat can be set to
either of 2 positions:
– A = high
– B = low
Locking front seat
C
When closing the front seat:
– Fold in knob for adjusting spring
strut
– Check that the front seat is
securely latched
• Swing down the rear of the seat
until it engages with an audible
click
• Close the left case (
b 32)
10LTbku6.book Seite 35 Freitag, 18. Mai 2007 11:40 11

BMW K 1200 LT Specifications

General

Displacement	1171 cc
Bore x Stroke	70.5 mm x 75 mm
Compression Ratio	10.8:1
Final Drive	Shaft drive
Fuel System	Electronic fuel injection
Torque	115 Nm at 5, 250 rpm
Transmission	5-speed
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual 320 mm discs
Rear Brakes	Single 285 mm disc
Power	98 hp (72 kW) at 6750 rpm
Wheelbase	1, 634 mm
