BMW K 1600 GTL Exclusive User Manual

Do not disconnect the battery
from the onboard electrical sys-
tem when jump-starting the
engine.
Remove the seat ( 73).
Allow engine on support mo-
torcycle to run while jump-
starting.
Begin by clamping one end of
the red jumper cable to the
positive terminal of the dis-
charged battery and clamping
the other end to the positive
terminal of the donor battery.
Then clamp one end of the
black jumper cable to the
donor battery's negative
terminal while connecting
the other end to discharged
battery's negative terminal.
Start engine of vehicle with dis-
charged battery in usual way;
if engine does not start, wait
a few minutes before repeat-
ing attempt in order to protect
starter motor and donor bat-
tery.
Allow both engines to idle for a
few minutes before disconnect-
ing jumper cables.
Disconnect jumper lead from
negative terminal first, then
from positive terminal.
Installing seat ( 74).
Light sources
Replace bulb for high-
beam headlight
NOTICE
The description below steps you
through the procedure for replac-
ing the left bulb. Replacement is
carried out in the same way on
the right side.
Turn slipstream deflector 1 out.
Remove screw 2 and work
side cover 3 to the rear and
remove.
Remove screw 1.
8
127
z Maintenance

BMW K 1600 GTL Exclusive Specifications

General

Displacement	1649 cc
Rear Suspension	BMW Motorrad Paralever
Rear Brakes	Single 320 mm disc, 2-piston caliper
Tire Front	120/70 ZR 17
Tire Rear	190/55 ZR 17
Engine Type	Liquid-cooled, 4-stroke in-line six-cylinder
Power	160 hp at 7750 rpm
Torque	175 Nm at 5250 rpm
Transmission	6-speed
Fuel Capacity	26.5 liters
Seat Height	750 mm
Weight	364 kg (unladen weight, road ready, fully fueled)
Front Suspension	BMW Motorrad Duolever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Length	2489 mm
Width	1000 mm
Wheelbase	1, 618 mm
Height	1, 465 mm
