BMW K1200GT User Manual

Turn the key to the LOCK
position in the case lock.
The case is closed.
Check that the case is se-
cure.
Topcase
OA
Open the topcase
Turn the key to the OPEN
position in the topcase lock.
The topcase is unlocked.
Press lock barrel 1.
Lever 2 pops up.
Pull the release lever up.
The lid of the topcase
opens.
Close the topcase
Pull release lever 2 all the
way up.
Close the lid of the topcase
and press it down. Check
that nothing is trapped
between the lid and the
case.
6
98
z Accessories

BMW K1200GT Specifications

General

Transmission	6-speed
Final Drive	Shaft
Front Brakes	Dual 320mm discs, 4-piston calipers
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Displacement	1157 cc
Power	152 hp @ 9500 rpm
Torque	130 Nm @ 7750 rpm
Seat Height	820/840 mm (32.3/33.1 in) (adjustable)
Dry Weight	249 kg
Weight (Wet)	approximately 282 kg
Front Suspension	BMW Duolever
Rear Suspension	BMW Paralever
Rear Brakes	2-piston caliper
