BMW R 1200 GS ADVENTURE Rider's Manual

Multifunction display
1 Clock ( 45), Panel for
RDC status indicators
OE
( 44), Panel for oil-level
information
OE
( 49)
2 Panel for warnings
( 21)
3 Panel for the on-board
computer's status indic-
ators
OE
( 46)
4 Gear indicator ( 20)
5 Engine-oil temperature
display ( 21)
6 Odometer reading
( 43)
7 Fuel gauge ( 20)
Warning and telltale
lights
1 Telltale light, left turn in-
dicator
2 Telltale light, high-beam
headlight
3 Warning light, general
4 Telltale light, neutral
5 Warning light, ABS (OE)
6 Telltale light, right turn
indicator
ABS warning light
OE
The way in which the ABS
warning light indicates status
can differ in some countries.
Possible national variant.
Function indicators
Fuel capacity
The horizontal bars be-
low the fuel-pump sym-
bol indicate the remaining
quantity of fuel.
Gear
Shows which gear is en-
gaged.
If no gear is engaged, the
gear indicator shows N and
the 'neutral' telltale light also
lights up.
3
20
z Status indicators

BMW R 1200 GS ADVENTURE Specifications

General

Displacement	1, 170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Length	2, 255 mm
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Wet Weight	260 kg
Fuel Capacity	30 liters
Tires Front	120/70 R19
Tires Rear	170/60 R17
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
ABS	BMW Motorrad Integral ABS
Seat Height	890 mm
