BMW R 1200 GS ADVENTURE Rider's Manual

The front seat can work
loose and wobble if the
two seat rods are not in the
same position.
Always be sure to install
both seat rods in the same
position.
Introduce the seat rod in
position 4.
Seat set to high position.
Introduce the seat rod in
position 5.
Seat set to low position.
Install the front seat ( 62)
Helmet holder
Using helmet holder
Remove the front seat
( 61)
The helmet catch can
scratch the panelling.
Make sure the lock is out of
the way when you hook the
helmet into position.
Attach the helmet to helmet
holder 1 by means of the
chin strap.
Install the front seat ( 62)
Mirrors
Adjusting mirrors
Pivot the mirror to the cor-
rect position by pressing
gently at the edge.
4
63
z Operation

BMW R 1200 GS ADVENTURE Specifications

General

Displacement	1, 170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Length	2, 255 mm
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Wet Weight	260 kg
Fuel Capacity	30 liters
Tires Front	120/70 R19
Tires Rear	170/60 R17
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
ABS	BMW Motorrad Integral ABS
Seat Height	890 mm
