BMW R 1200 GS ADVENTURE Rider's Manual

and cycles through the follow-
ing sequence:
Total distance covered
Tripmeter 1 (Trip I)
Tripmeter 2 (Trip II)
Residual range (once fuel
level is down to reserve)
Resetting tripmeter
Switch on the ignition.
Select the desired tripmeter.
Press and hold down
button 1 until the reading
changes.
The tripmeter is reset to
zero.
Residual range
Residual-range reading 1 ap-
pears accompanied by the
word
RANGE and indicates
how far you can ride with the
fuel remaining in the tank. On
a motorcycle not equipped
with an on-board computer
(OE), this reading is not dis-
played until the fuel level has
dropped to reserve. This dis-
tance is calculated on the
basis of fuel level and average
consumption.
When you refuel, the increase
in fuel level is not registered
unless several litres are ad-
ded to the fuel already in the
tank.
The residual range is
only an approximate
reading. Consequently, BMW
Motorrad recommends that
you should not try to use the
full residual range before
refuelling.
Tyre pressure
monitoring RDC
OE
Viewing tyre-pressure
readings
Switch on the ignition.
4
44
z Operation

BMW R 1200 GS ADVENTURE Specifications

General

Displacement	1, 170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Length	2, 255 mm
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Wet Weight	260 kg
Fuel Capacity	30 liters
Tires Front	120/70 R19
Tires Rear	170/60 R17
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
ABS	BMW Motorrad Integral ABS
Seat Height	890 mm
