BMW R 1200 GS ADVENTURE Rider's Manual

Position of the footbrake lever
for riding standing on the
pegs.
Adjusting footbrake lever
Make sure the ground is
level and firm and place the
motorcycle on its stand.
Push pedal 1 of the brake
lever forward and turn it to
the correct limit position.
The swivel lever engages
with an audible click.
Shift lever
Adjusting shift lever
Slacken screw 1.
Turn peg 2 to the desired
position.
You might experience
difficulties with gear-
shifts if the peg is set either
too high or too low. If you
have difficulties shifting gear
consult a specialist workshop,
preferably an authorised BMW
Motorrad dealer.
Tighten screw 1 to the spe-
cified tightening torque.
4
56
z Operation

BMW R 1200 GS ADVENTURE Specifications

General

Displacement	1, 170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Length	2, 255 mm
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Wet Weight	260 kg
Fuel Capacity	30 liters
Tires Front	120/70 R19
Tires Rear	170/60 R17
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
ABS	BMW Motorrad Integral ABS
Seat Height	890 mm
