BMW R 1200 RT Rider's Manual

Front seat
Removing front seat
Turn ignition key 2 clockwise.
Slightly raise front seat 1 at the
back.
Work front seat 1 to the rear to
disengage it from seat retainer
bridge 3 and remove.
with seat heating
OE
Disconnect plug 2 for the seat
heating.
Remove the front seat and
place it, upholstered side down,
on a clean, dry surface.
Installing front seat
with seat heating
OE
Connect plug 1 of the seat
heating.
4
90
z Operation

BMW R 1200 RT Specifications

General

Final Drive	Shaft drive
Tires (Front)	120/70 ZR 17
Tires (Rear)	180/55 ZR 17
Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Fuel Capacity	25 l
Seat Height	830 mm
Fuel System	Electronic fuel injection
Front Suspension	Telelever, central spring strut
Rear Suspension	Paralever, central spring strut
Front Brake	Dual 320 mm discs, 4-piston calipers
Rear Brake	Single 276 mm disc, 2-piston caliper
ABS	Standard
Wheelbase	1, 485 mm
