BMW S 1000R 2015 User Manual

Remove screws 1.
Disengage right side panel 2
from grommets 3, taking care
to start by disengaging the rear
first, and then work the side
panel forward to remove.
Installing right side panel
Begin by seating side panel 1
at the front and then seat
the rear of the panel in
grommets 2.
Install screws 3.
with engine spoiler
OE
Install engine spoiler 1, making
sure that retaining hook 2 is
secured.
Install screws 3.
Removing headlight
fairing
Switching off ignition ( 41).
9
134
z Maintenance
ProCarManuals.com

BMW S 1000R 2015 Specifications

General

Transmission	6-speed
ABS	Standard
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Max Power	160 hp (118 kW) at 11, 000 rpm
Max Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Weight	207 kg (456 lbs) fully fueled
Seat Height	814 mm (32 in)
Fuel Capacity	17.5 liters (4.6 gallons)
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Dual disc brakes, floating brake discs, diameter 320 mm
Rear Brakes	Single disc brake, diameter 220 mm
