Remove screws 1 and remove
windscreen 2.
Remove screw 1.
Ease left cover 2 aside and
disengage it from both hold-
ers 3.
Disconnect plug 4 for the
flashing turn indicators.
Remove screw 1.
Ease right cover 2 aside and
disengage it from both hold-
ers 3.
Remove cable tie arrow.
Disconnect plug 4 for the
flashing turn indicators.
Remove the right cover.
Remove screws 1 and head-
light fairing 2.
Installing headlight fairing
Hold headlight fairing 1 in posi-
tion and secure with screws 2.
9
135
z
Maintenance
