BMW S 1000XR User Manual

Red: (Hot! / High!) current
temperature or value is too
high.
White: (---) no valid value avail-
able. Dashes 5 are displayed
instead of a numerical value.
NOTICE
The assessment of some values
is only possible from a certain
journey duration or speed. If a
measured value is still not being
displayed because the conditions
for measurement have not been
met, dashes are displayed in-
stead as a placeholder. If there
are no valid measured values,
there will be no assessment in
the form of a coloured symbol.
Check Control dialogue
Messages are output as Check
Control dialogues 1.
If there are two or more Check
Control messages of equal
priority, the messages keep
changing in the order of their
occurrence until they are ac-
knowledged.
If symbol 2 is actively dis-
played, it can be acknowledged
by tilting the Multi-Controller to
the left.
Check Control messages are
dynamically attached as addi-
tional tabs on the pages in the
menu My vehicle ( 101).
You can go to the message
again as long as the fault per-
sists.
3
37
z Status indicators

BMW S 1000XR Specifications

General

Displacement	999 cc
Max Power	165 hp (121 kW) at 11, 000 rpm
Max Torque	114 Nm (84 lb-ft) at 9, 250 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Aluminum composite bridge frame, partially self-supporting engine
Traction Control	Dynamic Traction Control (DTC)
Wheelbase	1, 548 mm (60.9 in)
Seat Height	840 mm (33.1 in)
Dry Weight	226 kg (498 lbs)
Fuel Capacity	20 l (5.3 gal)
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Twin disc, 320 mm, 4-piston radial calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
ABS	BMW Motorrad ABS Pro
