Description of callouts for the keypad overview figure
Callout
number
Description
1 Power indicator LED
2 Feature key (refer to Feature key, page 39)
3 Status indicators (refer to Status indicators
overview, page 38))
4 Main display area (refer to Main display area,
page 32)
5 Ribbon bar (refer to Ribbon bar overview,
page 36)
6 Integrated proximity reader (for use with
tokens and cards)
7 Presence sensor (lights a dim screen as you
approach)
Your security system provides quick access to functions
through the keypad menus.
My shortcuts are:
___________________________ ___________________________
___________________________ ___________________________
Control Panels B94x Keypad operation overview | en 31
Bosch Security Systems, Inc. 2014.04 | 05 | F.01U.287.176
