34 | Refrigerant Pressure ranges EP Series
EP Series
8733953041 (2019/01)
Subject to change without prior notice
REFRIGERANT PRESSURE RANGES
Enteri
ng
Fluid
Temp
°
Fluid
COOLING HEATING
Entering Air Temp (Dry Bulb) Entering Air Temp (Dry Bulb)
70° F 75°F 80° F 60 °F
70° F
Suction Discharge Suction Discharge Suction Discharge Suction Discharge Suction Discharge
30
5 68-79 233-266 71-84 269-316
10 65-76 222-255 68-80 255-291
15 59-71 216-248 62-75 245-283
40
5 113-147 138-156 117-152 142-161 119-155 145-164 80-95 244-282 85-100 289-317
10 113-147 145-164 117-152 150-170 119-155 153-173 77-91 237-274 82-96 269-306
15 113-147 151-170 117-152 156-175 119-155 159-179 72-86 226-262 76-90 258-297
50
5 115-149 164-185 119-154 170-191 121-157 173-195 95-113 255-302 100-119 287-337
10 115-149 173-194 119-154 178-200 121-157 182-204 91-109 248-290 96-115 281-323
15 115-149 179-200 119-154 184-207 121-157 188-211 86-103 237-282 90-108 269-316
60
5 117-151 194-218 121-156 200-224 123-159 204-229 111-133 270-324 117-141 302-360
10 117-151 204-228 121-156 211-235 123-159 215-240 106-129 258-311 112-136 294-341
15 117-151 211-235 121-156 218-242 123-159 222-247 101-122 251-302 106-128 283-337
70
5 119-153 228-254 122-158 235-262 125-161 240-267 129-158 282-343 136-167 314-378
10 119-153 238-265 122-158 246-273 125-161 251-279 124-150 274-333 131-159 307-362
15 119-153 246-273 122-158 254-281 125-161 259-287 117-146 262-320 123-154 294-355
80
5 121-155 265-294 124-160 273-303 127-163 279-309 148-184 299-366 156-194 331-405
10 121-155 276-306 124-160 285-316 127-163 291-322 143-176 286-352 151-185 322-383
15 121-155 285-315 124-160 294-325 127-163 300-332 136-169 278-343 143-179 311-378
90
5 123-157 306-337 126-162 316-348 129-165 322-355
10 123-157 319-351 126-162 329-363 129-165 336-370
15 123-157 329-362 126-162 339-373 129-165 346-381
100
5 124-159 351-387 128-164 363-399 131-167 370-407
10 124-159 367-403 128-164 378-416 131-167 386-424
15 124-159 376-413 128-164 388-426 131-167 396-435
110
5
126-161 403-441 130-166 416-455 133-169 424-464
10 126-161 419-458 130-166 432-472 133-169 441-482
15 126-161 429-470 130-166 443-485 133-169 452-495
This chart shows approximate temperatures and pressures for a unit in good repair. The values shown are meant as a guide only and
should not be used to estimate system charge.
This chart assumes rated air flow and 80
° d.b./67° w.b. entering air temperature in cooling, 70° d.b entering air temperature in
heating. Heating data at entering fluid temperatures below 50° assumes the use of antifreeze.
As a result of continuing research and development, specifications are subject to change without notice.
