Vertical dimensions | 35EP Series
8733953041 (2019/01)
EP Series
VERTICAL DIMENSIONS
ABC D E F GH J K M N P Q
Width Depth Height
Discharge
Depth
Discharge
Width
Cabinet
Edge to
Discharge
Left Side
to
Discharge
Water
In
Bottom to
Condensate
Drain
Water Out
R/A
Duct
Width
R/A
Duct
Flange
Height
Filter Rack
Height
Right
Side to
Discharge
EP007 21.75 21.75 32.75 11.75 7.75 5.00 8.50 2.25 8.00 13.75 18.00 13.00 15.00
5.32
3/4" FPT 15 x 20 x 1
EP009 21.75 21.75 32.75 11.75 7.75 5.00 8.50 2.25 8.00 13.75 18.00 13.00 15.00
5.32
3/4" FPT 15 x 20 x 1
EP012 21.75 21.75 32.75 11.75 7.75 5.00 8.50 2.62 7.50 12.50 18.00 16.00 18.00
5.32
3/4" FPT 18 x 20 x 1
EP015 21.75 21.75 39.25 13.75 13.75 4.00 6.12 2.25 7.50 12.25 18.00 18.00 20.00 4.00 3/4" FPT 20 x 20 x 1
EP018 21.75 21.75 39.25 13.75 13.75 4.00 6.12 2.25 7.50 12.25 18.00 18.00 20.00 4.00 3/4" FPT 20 x 20 x 1
EP024 21.75 26.25 47.25 13.75 15.75 6.25 4.87 2.50 8.75 15.00 22.00 22.00 24.00 4.00 3/4" FPT 24 x 24 x 1
EP030 24.25 33.50 47.25 15.75 15.75 8.87 7.00 2.50 8.50 14.50 28.00 22.00 24.00 4.00 1" FPT 24 x 30 x 1
EP036 24.25 33.50 47.25 15.75 15.75 8.87 7.00 2.50 8.50 14.50 28.00 22.00 24.00 4.00 1" FPT 24 x 30 x 1
EP042 26.25 33.50 58.25 17.75 17.75 7.87 6.75 3.25 8.50 13.25 28.00 30.00 32.00 4.00 1" FPT 16 x 30 x 1 (2)
EP048 26.25 33.50 58.25 17.75 17.75 7.87 6.75 3.25 8.50 13.25 28.00 30.00 32.00 4.00 1" FPT 16 x 30 x 1 (2)
EP060 26.25 33.50 66.25 17.75 17.75 7.87 7.00 3.25 8.50 13.25 28.00 38.00 40.00 4.00 1" FPT 20 x 30 x 1 (2)
EP070 26.25 33.50 66.25 17.75 17.75 7.87 7.25 4.25 10.00 17.00 28.00 38.00 40.00 3.00 1" FPT 20 x 30 x 1 (2)
Model
Condenser
Water
Conn
ections
Recommended
Replacement
Nominal
Filter Size
