6 Transport and storage
▶ Always observe the required ambient conditions for transport and storage, see
Chapter6.2 “Storing the axial piston unit” on page38.
Information on unpacking can be found in chapter7.1 “Unpacking” on page40.
6.1 Transporting the axial piston unit
The following transportation options are available depending on the weight and
duration of transport:
• Transporting with a lifting device (eye bolt or lifting strap)
Table 8: Dimensions and weights (without through drive) of A4VSO
Size 40 71 125 180 250 355 500 750 1000
Ground kg 55 68 100 115 197 220 335 475 620
Width mm Dimensions vary by equipment. The values applicable for your axial piston
unit can be found in the installation drawing (request if necessary).
Height mm
Depth mm
Weight may vary by equipment.
6.1.1 Transporting with a lifting device
For transporting, the axial piston unit can be connected to a lifting device via an eye
bolt in the drive shaft or in the housing. Alternatively, it can also be transported with
a lifting strap.
Only use the lifting strap if you are unable to achieve the required installation
position with transport using the eye bolts.
The axial piston unit can be transported suspended from an eye bolt screwed into
the drive shaft as long as only outward (pulling) axial forces are applied.
▶ For all female threads, use a stud end from the same system of units and of the
correct size.
▶ To do this, screw an eye bolt completely into the female thread on the drive shaft.
The thread size is stated in the installation drawing.
▶ Make sure that the eye bolt can bear the total weight of the axial piston unit
plus 20%.
You can hoist the axial piston unit as shown in Fig. 9 with the eye bolt screwed into
the drive shaft.
Dimensions and
weights
Transport with eye bolt in
the drive shaft
