96/104 Technical data
Bosch Rexroth AG, A4... with HS5E pilot control valve/Series 3x, RE 92076-01-B/10.2017
15 Technical data
The permissible technical data values for your axial piston unit can be found on data
sheet92076.
The data sheet can be found on the internet at
www.boschrexroth.com/mediadirectory
Additional information can be found in the online product catalog
Mobile Hydraulics: www.boschrexroth.com/axial-piston-pumps
Order-related technical data for your axial piston unit can be found in the order
confirmation.
15.1 Electrical connection of the pilot valve
Table 28: Electrical Datas
Type HS5E
Supply voltage
1)
Nominal voltage 24VDC
Lower limit value 18VDC
Upper limit value 36VDC
Maximum permissible
residual ripple
2.5Vss
Power consumption Maximum 40W
Required external fuse
protection
4A, slow-blow
AD/DA resolution Analog inputs 12bit
Analog outputs
2)
10bit
Actual pressure value
Input XH4,
Pins 10 and 11
Analog voltage 0 to 10V
Analog current 0 to 20mA
With configuration to current
input:
Maximum permissible input
current 30mA
Ambient temperature range
at the pump
v
-20 to +60°C
Storage temperature range
of pump/electronics
v
0 to +70°C
1)
Supply voltage is used directly for sensor connections X2M1, X2M2, and X8M (no internal
voltage limitation)
2)
Outputs can be parameterized; for as-delivered condition, see page52
The following table shows the pin assignment of the central connector 11 + PE for
pilot control valve HS5E. The column “code” refers to the cable kit that can be
ordered as optional accessories.
The following cable sets can be ordered from Bosch Rexroth:
Type: Plug-in connector 11+PE for central connector XH4
• Without cable (assembly kit) Mat. no. R900884671
• With cable kit 2 x 5 m Mat. no R900032356
• With cable kit 2 x 20 m Mat. no R900860399
• Ethernet M12 connecting cable, please contact Rexroth for the material number.
(Please contact us if the unit is to be used outside the specified range of values)
Pin assignment of central
connector
