ctrlX CORE X7
License dongle
Bosch Rexroth AG
R911419122, Edition 01
5 Spare parts, accessories and wear parts
5.1 Power connector, 24 V
Ordering code Part number Description
XACC-1-CSPWRM R911416670 24 V power connector
5.2 SD card
Ordering code Part number Description
XACC-0-SD016GB R911404022 Micro SD card, 16 GB
5.3
RJ45 cable
Ordering code Part number Description
RKB0020 R911340676 Bus cable
5.4
End clamp
Ordering code Part number Description
SUP-M01-ENDHALTER R911170685 2 pieces of snap-on end brackets for 35 mm NS
35/7.5 support rail; width: 9.5 mm
5.5
Fan unit
Ordering code Part number Description
COOLING CTRL. UNIT R911417624 Fan unit
5.6
Endcover
Ordering code Part number Description
XACC-2-ENDCOVR R911412178 Endcover
5.7 License dongle
The license dongle allows to easily transmit licenses between ctrlX controls. The license dongle is a
micro SD card with a serial number. The user can assign licenses to the dongle instead of to the ctrlX
controls.
Ordering code Part number Description
XACC-1-SD*000L R911416693 License dongle
Spare parts, accessories and wear parts
