12 Device description
12.1 ctrlX CORE control
The ctrlX CORE is a high performance compact control in embedded format suitable for the support rail
mounting and for its use in a control cabinet.
With Quad Core Intel® Core
TM
/I7-CPU of the 11th generation, the ctrlX CORE has sufficient computing
performance for complex control tasks. The Linux-based operating system is open for the integration
of all ctrlX CORE runtime and ctrlX CORE engineering apps from the ctrlX WORKS function module kit
and other further customized apps. A central ctrlX Data Layer is used to exchange the communication
between the apps in realtime and non-realtime.
The onboard EtherCAT master is used to connect and control the drives, I/O modules and other devices
from the open EtherCAT ecosystem.
Device description
